Productdetails:
|
| Max Resolution: | 1920*1080P | Frame rate: | 1080P/fps/30fps, 720P/30fps |
|---|---|---|---|
| Focustype: | hand | Sensor: | CMOS |
| Inputinterface: | USB2.0 | Kabellengte: | 100cm |
| Materiaal: | ABS+METAAL | Verpakkingsgrootte: | 8*8*5cm |
| Markeren: | 720P USB-Frambozenpi Camera,CMOS USB Cameramodule,1MP USB-de Module van de Frambozenpi Camera |
||
De volgende parameters vertegenwoordigen niet de definitieve versie van het product, zullen alle parameters volgens uw vereisten worden gemaakt!!!
| ModelNo. | 1080P webcam |
| CMOS | 1/2.9“ |
| Beeldformate | MJPEG/YUY2 (YUYV) |
| Suppotresolutie en kader |
1920x1080@30fps MJPEG/1280x1024@30fps MJPEG 1280x960@30fps MJPEG/1280x720@ 30fps MJPEG 1024 x 768@ 30fps MJPEG/800 x 600@ 30fps MJPEG 640x480@ 30fps MJPEG/320x240@ 30fps MJPEG 3840x2160@1fpsYUY2/2592x1944@ 1fpsYUY2 2048x1536@3fpsYUY2 /1600x1200 @3fpsYUY2 1920x1080@3fpsYUY2/1280x1024@3fpsYUY2 1280x960@5fpsYUY2/1280x720@5fpsYUY2 1024 x x 768@5fpsYUY2/800 600@20fpsYUY2 640x480@ 30fpsYUY2/320x240@ 30fpsYUY2 |
| Schakelaartype | USB2.0 hoge snelheid |
| AEC | steun |
| AEB | steun |
| AGC | steun |
| Regelbare parameters | llightness, Contrast, Verzadiging, Tint, Scherpte, Gamma, Witbalans, Backlight-Contrast, Blootstelling |
| Lens |
Grootte: 1/2.3, gezichtsveld: 100Degree Relatieve Verlichting (Sensor): 70% De filter van IRL: 650±10nm |
| Macht | USB-BUSmacht 4P2.0MM |
| Voltage | DC5V |
| Huidig | 200mA |
| Grootte | 50mm × 25mm |
| Voorraadtemprature | -20°C aan 70°C |
| Het werk temprature | 0°C to60°C |
| USB-kabel | 1M (2M/3M/5M) |
| Steunregeling |
Winst XP/Vista/Win7/Win8 /Linux met UVC (boven Linux-2.6.26) MacOs X 10.4.8 of laat/Android 4,0 of hierboven met UVC |
